Get the Heat out of the Electronics

Published On: March 15, 2017By

If you have high-powered LEDS, or a power supply, or are trying to control larger motors, you have to get a lot of heat out of your circuit boards. The classic way to dissipate heat is to bolt your power transistor to an aluminum heat sink. That is a slow, messy, and expensive proposition, especially if you need thermal grease between the transistor and heat sink. The 5V regulator (IC7805) can supply more power when bolted to an aluminum heatsink using thermal grease to better transfer the heat.

Another problem with bolted-up heatsinks is that the assembly operation is less controlled. Circuit board fabrication and assembly are tightly-controlled repeatable processes. When you have people hand-assembling things there is a greater chance for errors. This is especially true if the people doing the work are on the other side of the world, speak a different language, and are functionally illiterate.

It’s always a good idea to make thermal management inherent in your PCB design. Experience has shown you can get about 2W of heat out of a 3×5” copper area on a conventional FR4 PCB. Wayne Yamaguchi learned some great thermal design tips for his kits to convert a Maglite to an LED flashlight. He thought the hard part would be the switching regulator design. It turns out the mechanical engineering and thermal design was the hardest thing. Wayne Yamaguchi found that Linear Tech had made the circuit design for his LED Maglite kit easy, it was the thermal design that took the most work.

Wayne figured out how to use vias and copper pours to get the heat of the LED transferred to the aluminum body of the Maglite. Getting the heat out is why LED flashlights are not made of plastic. An LED is more efficient than an incandescent bulb, but the incandescent bulb radiates its waste heat out as IR (infrared) light, along with the viable light. The heat made by an LED stays in the LED.

The first place you look to dissipate more heat is in the PCB copper. You may want to experiment with thicker copper. Normal PCBs have 1 oz copper, or 1 oz plated up to 2 oz copper. That is measured in ounces per square foot. To covert to the actual thickness in mils (thousandths of an inch), you multiply by 1.37. It’s easy to order PCBs with 6oz/ft2 copper foil. Then you go to what PCB fabricators call “heavy copper,” where the weight can get up to 20oz/ft^2, that is, 27.4 mils thick. If you need even thicker, you can shop around for a PCB fab house that does “extreme copper.” This is anything above 20 oz/ft^2 thickness.

Any airflow over a heatsink or copper planes will greatly improve heat flow. If you uncover the solder mask of the plane, it improves heat transfer to ambient. Do not finish these large bare copper areas with HAL (hot-air-leveling). The solder can pile up and while it will improve heat dissipation, it will make big droopy lumps of solder. It is better to nickel plate or use gold immersion finishes. Both will protect the copper from corrosion and the gold finish looks great.

When the PCB cannot get enough power out, you can increase the number of output transistors, if you have the board area to spend. Linear Tech helps you do this with their linear regulators that you can parallel together. If you have a 5W dissipation, you can use three devices in parallel. Each device is good for 2W if you give it enough PCB copper area to dissipate that heat. You can use interior planes to move the heat, but remember, you have to use vias to stitch to the inside planes, since ultimately, you have to get the heat to the outside air.

If paralleling surface-mount devices (SMD) and thicker PCB copper is not enough, you might look at transistors like International Rectifiers “Direct FET” line, also know as Infineon’s CanPAK. They have a package that lets you mount a heatsink on the top. Now you can use all the thick and heavy copper tricks on three terminals. You can also bond, press, or solder a heat sink on the top of the part, which is the die lead-frame. The CanPAK package from Infineon transfers the heat from the back to the chip die to the PCB using a broad metal frame.

For switching regulators with internal FETs, or conventional packaged FETs, you can also use a gull wing or top-hat heatsink that transfers the heat from the PCB to the air. The great thing about this solution is that you can use pick-and-place assembly for the heatsinks like the other parts on your board. Then you send the board into your normal IR reflow oven to solder both the part and the heatsink. Do make sure that your CAD “insert” file places the heatsink after the FET is placed. You should make a note on the assembly drawing as well. Top hat heat-sinks take the heat out of your PCB and allow pick-and-place assembly (courtesy Fischer Elektronik).

Putting a heat sink on the plastic part will have little value. The heat travels through the plastic package so slowly that a metal heat sink on the plastic does very little to cool the silicon die itself. The best place to remove heat is through the lead-frame that the die is mounted to. In most parts, that lead frame is also the ground or common, or the V− pin. Some CMOS parts have the lead-frame connected to V+. Check with the IC company before you make assumptions on how to remove the heat.

When you really need to move a lot of heat, perhaps in a hot environment like under the hood of a car, you can go to metal-core PCBs (Figure 6). The nice thing about metal core PCBs is that they move a tremendous amount of heat, and they are also strong structural components. The bad side is that metal-core PCBs tend to be expensive in low volume. PCBPool can do prototyping services for metal-core PCBs. Metal-core PCBs are often the only way to get enough heat out of LED circuits (courtesy Bergquist/Henkel).

There is a newer proprietary heat and high-current PCB technology. The company Häusermann, calls the process HSMtec. They bend and bond 20 mil wires to the board. These wires and strips piggyback on existing traces you design on the PCB. So now any narrow trace can carry much more current and heat. The 2 mil thin strips can be quite wide, so you get the same benefit as extreme copper or metal-core PCBs.

So whether you are designing an LED lamp or an electric drag racer, know your options and the need to get the heat out of the electronics. If you make sure to design for worst-case conditions and actually test at these conditions, you can assure a long and happy life for your designs.
